1) Auto OTDR 2) Expert OTDR 3) Event Map 4) Optical Power Meter 5) Optical Light Source 6) Insertion Loss 7) Visual Fault Locator 8) Rj45 Cable Tracking 9) Rj45 Cable Sequence 10) Rj45 Cable Length 11) Endface Inspector 12) LED Light
Features
1) Useful light-weight OTDR 2) Combines all essential fiber tests in one handheld with OPM, OLS, VFL, etc 3) Easy to understand OTDR analysis with event list 4) PON network verification or troubleshooting 5) Upgrades easily in the field 6) All-day battery life
Model#
980MAS-S0
980MAS-S1
980MAS-S2
980MAS-P1
980MAS-P2
Wavelength
1550nm
1310nm & 1550nm
1310nm & 1550nm
1310nm
1610nm
Dynamic Range
24dB
24/22dB
26/24dB
26dB
22dB
Testing Range
3m to 80km
3m to 80km
3m to 100km
3m to 100km
3m to 60km
OTDR
√
√
√
√
√
Power Meter
√
√
√
√
√
Light Source
√
√
√
√
√
Visual Fault Locator
√
√
√
√
√
Insertion Loss Testing
√
√
√
√
√
Event Map
√
√
√
√
√
RJ45 Sequence
√
√
√
√
√
RJ45 Length
√
√
√
√
√
Rj45 Digital Tracker
√
√
√
√
√
In-service Testing
x
x
x
√
√
980MAS-P1 & 980MAS-P2 are both with Wavelength Filter. In-service signal power <-5dBm @ 980MAS-P1, <0dBm@980MAS-P2
The Menu Languages - English - Russian - Korean - French - Spanish - Vietnam
The kit includes, - OTDR - FC/SC Connector - User Manual - PC Software - Charging Adapter - RJ45 Cable Tracker - RJ45 Remote Unit - USB Cable - Carrying Bag - Certificate of Calibrate
FirstFiber Technologies offers two types of customization services for you to choose from, Light Customization and Deep Customization. You can refer to the detailshere. If you would like a Light Customization based on the 980MAS OTDR, please provide requirements according to the instructions below. If you prefer a Deep Customization, please contact our sales team to discuss the details.
Instructions
Model Number
Max 8 characters, no special characters allowed.
Logo
High Resolution. (.jpg, .bmp, .psd, .cdr, etc)
Boot Screen
800x480 px, format .bmp, and color depth 16-bit
Language
Please contact sales to request the English version of the field list.
Light customization (Model, LOGO, and Language) are 100% FREE OF CHARGE, but MoQ 20
Standard Packaging
Model
Qty/Carton
Net Weight
Gross Weight
Size
980MAS
10
9.5 KG
11.5 KG
53x23x26cm
Non-Standard Packaging
Model
Qty/Carton
Net Weight
Gross Weight
Size
980MAS
1
0.95 KG
1.3 KG
23x13x16cm
At FirstFiber Technologies, all test instruments are dispatched via DHL Air Express, reaching global destinations within 3 to 7 days. Please note that the downloadable shipping price list is for reference only. For precise shipping costs, please refer to the final quote provided by your sales representative.
